3M™ Adhesive Transfer Tape 468MP offers outstanding adhesion on metal and high surface energy plastics. 3M™ High Performance Acrylic Adhesive 200MP delivers excellent shear strength to resist slippage and edge lifting. Temporarily repositionable for placement accuracy, this tape also performs well after exposure to humidity and hot/cold temperatures.
Outstanding Adhesion on Metals and HSE Plastics
3M™ Adhesive Transfer Tape 468MP features a 5.2 mil adhesive for splicing and laminating procedures using metals and HSE plastics. The thicker caliper adds wet-out capability for surfaces where adhesion may be compromised by slight textures or irregularities. 3M™ High Performance Acrylic Adhesive 200MP is delivered on a 4.2 mil, 58 lb. polycoated kraft paper liner which is excellent for rotary processing of graphic and die cut parts. This adhesive transfer tape also resists solvents, humidity and moisture, as well as heat up to 400°F / 204°C for short periods.
Recommended Applications
Featuring 3M™ High Performance Acrylic Adhesive 200MP
More than 30 years ago, 3M™ High Performance Acrylic Adhesive 200MP set the standard for bonding metal and high surface energy plastics. Today, this high-performance adhesive provides even higher levels of performance, with exceptional peel and shear strength for precision bonding. It offers excellent moisture and solvent resistance which enable it to form resilient, durable bonds that conform to a wide variety of applications. Once bonded, this adhesive will provide outstanding shear strength to resist edge lifting and slippage. 3M™ High Performance Acrylic Adhesive 200MP also offers excellent short-term heat resistance and will continue to perform at temperatures up to 400°F / 204°C.
Understanding Adhesive Transfer Tapes
Adhesive transfer tapes are rolls of pressure sensitive adhesive pre-applied to a special release liner. For application, the tape is simply pressed, adhesive side down, to a surface and the liner is peeled off. A variety of adhesive properties and liners are available to meet requirements for applications such as nameplate attachment to high and low surface energy plastics, appliance graphic overlays that perform in high temperatures, foam gasketing, web splicing, signs, posters, banners, point-of-purchase displays, and more.
Bringing Better Ideas to the Surface through Science
In our 3M Industrial Adhesives and Tapes Division, we apply the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, our technologies help customers like you deliver competitive products to the market faster and more efficiently.
Pressure Sensitive Adhesive properties are frequency and temperature sensitive. 3M has developed Material Data Cards (MDCs) for common 3M PSAs for use with many commercially available FEA software applications. Learn more.
| Adhesive Type | Acrylic |
| Application | Large Surface Lamination Assembly, Gasket Assembly, Mounting & Trim Attachment |
| Automotive OEM Specification | FCA 9.55368, FCA MS-CC240, Ford WSS-M11P62, GMW 14892, Ford WSS-M99P48-A3, GM 9985274 |
| Brands | 3M™ |
| Indoor/Outdoor | Indoor/Outdoor |
| Industries | Metalworking, MRO, Point of Purchase, Print, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Aerospace, Appliance, Specialty Vehicle, Transportation, Woodworking, Military & Government, Signage |
| Maximum Operating Temperature (Celsius) | 204 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 400 ℉ |
| Minimum Operating Temperature (Celsius) | -40 ℃ |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Primary Liner | 58# Polycoated Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness (Imperial) | 4.2 mil |
| Primary Liner Thickness (Metric) | 0.11 mm |
| Shelf Life | 18 Month |
| Smallest Saleable Unit | Roll |
| Total Tape Thickness without Liner (Imperial) | 5.2 mil |
| Total Tape Thickness without Liner (Metric) | 0.132 mm |
| Units per Case | 72.0 Roll |
| Overall Length (Imperial) | 60 yd |
| Overall Length (Metric) | 54.86 m |
| Overall Width (Imperial) | 0.5 in |
| Overall Width (Metric) | 12.7 mm |
