3M™ Pin Strip Header .039" (1.0 mm) 9X9 Series

3M ID B5005541002
UPC 00068060599841

Offer positions 6-80

Straight and sufracemount applications

Gold flash plating

View more details

Frequently viewed resources

Tech Data Sheet (PDF, 1MB)

Find a part

Details

Highlights

Offer positions 6-80
Straight and sufracemount applications
Gold flash plating
Space-saving design

3M™ Pin Strip Header .039" (1.00 mm) 9X9 Series offers space saving design at half the pitch of standard 2mm boardmount headers. Enables design flexibility in board to board and wire to board for small devices.

Typical properties

Details

Brands	3M™
Connector Style	Pin Header
Number of Contacts	6 , 8 , 10 , 16 , 20 , 22 , 26 , 30 , 40 , 50 , 60 , 80
PCB Mounting Angle	Straight
PCB Mounting Style	Surface Mount
Pitch (Imperial)	0.039 in
Pitch (Metric)	1 mm
Product Series	949, 959
Tech Sheet Number	TS-2803

Resources

3M™ Pin Strip Header, .039" (1.00MM), 9X9 Series Tech Data Sheet

Data Sheets

(PDF, 1MB)
