3M™ Double Coated Tape GPT-020 is a transparent double coated pressure sensitive adhesive (PSA) tape with clear polyester carrier delivered on a paper liner. The tape is transparent and 200 microns (8 mils) thick. It features a modified solventless acrylic adhesive that combines a high level of peel and shear performance enabling high adhesion to a wide variety of substrates, both to high and some low surface energy materials. It offers high initial tack and humidity resistance, and provides high temperature resistance up to 375°F (190°C) with 500g/1”x1” and up to 320°F (160°C) with 1000g/1”x1”per SAFT, PSTC 17.
It offers high initial tack and humidity resistance. Providing high temperature resistance 190˚C short term and 90 ˚C long term.
| Adhesive Type | Acrylic, High Tack Acrylic |
| Back Side Adhesive Thickness (Imperial) | 3.75 mil |
| Back Side Adhesive Thickness (Metric) | 0.095 mm |
| Back Side Adhesive Type | Acrylic |
| Backing (Carrier) Material | PET, Paper |
| Backing (Carrier) Thickness (Imperial) | 0.47 mil |
| Backing (Carrier) Thickness (Metric) | 0.012 mm |
| Brands | 3M™ |
| Face Side Adhesive Thickness (Imperial) | 3.75 mil |
| Face Side Adhesive Thickness (Metric) | 0.095 mm |
| Face Side Adhesive Type | Acrylic |
| Maximum Operating Temperature (Celsius) | 160 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 330 ℉ |
| Primary Liner | 58# Polycoated Kraft Paper (PCK) |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 3.9 mil |
| Primary Liner Thickness (Metric) | 0.1 mm |
| Product Color | Transparent |
| Shelf Life | 18 Month |
| Smallest Saleable Unit | Roll |
| Total Tape Thickness without Liner (Imperial) | 7.95 mil |
| Total Tape Thickness without Liner (Metric) | 0.2 mm |
| Units per Case | 10.0, 16.0, 17.0, 20.0 |
| Overall Length (Imperial) | 54.7 yd, 547 yd |
| Overall Length (Metric) | 50 m, 500 m |
| Overall Width (Imperial) | 0.35 in, 0.47 in, 0.6 in, 0.75 in, 1 in, 1.5 in, 2 in, 39.4 in, 60.6 in |
| Overall Width (Metric) | 9 mm, 12 mm, 15 mm, 19 mm, 25 mm, 38 mm, 50 mm, 1000 mm, 1540 mm |
Other
(PDF, 105KB)
