Scotch® Photoelectric Scanning Tape 7800 is an exposed-lens retroreflective tape with a pressure-sensitive adhesive that is designed for use as expendable code marks in automatic warehouse or conveyor operations. This product affords exceptional contrast with its background for increased accuracy, reliability, and depth-of-field in photoelectric sorting and classification systems and may be employed with automatic on-line applicators or manual dispensers for identification or simple sortation of paperboard shipping containers.
A Durable Labeling Alternative to Aluminum Nameplates
3M™ Foil Label Materials deliver a combination of durability and visual impact that is ideal as a cost-effective replacement for heavier, more costly aluminum nameplates in a full range of applications. These materials feature an aluminum foil facestock in bright or matte finish. Facestocks are vinyl topcoated and printable with conventional or UV inks using flexographic, letterpress or screen printing processes. Labels can also be embossed with dot matrix impact printers. Our 3M™ Acrylic Adhesive 320 is formulated for permanent application on flat or curved surfaces, and for long term reliability even in difficult conditions. The 1.7 mil acrylic adhesive coat is ideal for wet-out on textured surfaces. Materials are available with 60# densified kraft or 90# polycoated kraft liners for efficiency in rotary, roll to roll processing.
Recommended Applications
About 3M™ Adhesive 320
3M™ High Tenacity Acrylic Adhesive 320 delivers excellent flagging resistance even on curved surfaces, and is designed for long term adherence in a range of conditions. It is suitable for flexographic and thermal transfer print technologies. This adhesive is UL Recognized (File MH11410) and CSA Accepted (File 099316).
Bringing Better Ideas to the Surface through Science
In our 3M Industrial Adhesives and Tapes Division, we apply the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, our technologies help customers like you deliver competitive products to the market faster and more efficiently.
| Adhesive Thickness (Imperial) | 1.7 mil |
| Adhesive Thickness (Metric) | 0.04 mm |
| Adhesive Type | Solvent Acrylic |
| Backing Material | Aluminum Foil |
| Backing Thickness (Imperial) | 2 mil |
| Brands | Scotch® |
| Core Size (Imperial) | 3 none |
| Core Size (Metric) | 76 mm |
| Face Side Adhesive Thickness (Imperial) | 1.7 mil |
| Face Side Adhesive Thickness (Metric) | 0.04 mm |
| Face Side Adhesive Type | 320 High Tenacity Acrylic |
| Facestock Color | Silver |
| Facestock Material | Aluminum Foil |
| Facestock Thickness | 2 mil |
| Facestock Thickness (Metric) | 0.05 mm |
| Industries | Consumer Goods, Electronics, Automotive, General Industrial, Converter Solutions, Medical, Military & Government, Packaging, Specialty Vehicle, Transportation |
| Label Form | Roll |
| Maximum Operating Temperature (Celsius) | 176.67 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 350 ℉ |
| Minimum Operating Temperature (Celsius) | -40 ℃ |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Nominal Adhesive Thickness (Imperial) | 1.7 mil |
| Primary Liner | 60# Densified Kraft |
| Primary Liner Color | Brown |
| Primary Liner Thickness (Imperial) | 3 mil |
| Primary Liner Thickness (Metric) | 0.08 mm |
| Printing Method | DMI, Flexo, Thermal Transfer |
| Product Color | Silver |
| Product Type | Label |
| Removability | Not Removable |
| Smallest Saleable Unit | Roll |
| Surface Finish | Matte |
| Tape Structure - Reflective Technology | Exposed-Lens Reflective Tape |
| Tape Thickness (Imperial) | 3.7 mil |
| Topcoat | TC |
| Overall Thickness (Imperial) | 7 mil |
| Overall Width (Imperial) | 40 in |
| Overall Width (Metric) | 1016 mm |
