3M™ Cold Shrink QS4 Integrated Splice Kits 15-SP Series
- | Select product options for IDs.
Details
Highlights
- Inline splice for joining JCN, flat strap neutral, tape shield and LC cables
- Special-electrode design reduces electrical stress at critical cable and splice interface
- Designed for feeder and distribution circuits, size transition splicing, direct-burial installations and submerged locations
- Rated for 15 kV applications
- Withstands a temperature range of 221 to 284 °F (105 to 140 °C)
The new 3M™ Cold Shrink QS4 Integrated Splice Kit is a premier offering that utilizes our field-proven 3M™ Cold Shrink QS-III Splice Body with additional features that make installation quick and easy. This exciting product integrates all of the layers of a shielded power cable splice into one compact joint.
With this splice, 3M is introducing our easy-to-use yellow core and rejacketing tube. We incorporated our smooth-edged shield sock (non-fraying ends) with optional customizable ground braid. The Shielded Power (SP) inline splice kits below are designed for joining Jacketed Concentric Neutral (JCN), Flat Strap Neutral, Tape Shield and Longitudinally Corrugated (LC) power cables. The splice includes a 4 AWG, four-foot long integrated ground braid for attaching to an external ground (factory installed ground braid extends approximately four feet beyond the end of the rejacketing after installation). Note: Cable sizes shown below are for standard insulation thickness. Final determining factor is cable insulation O.D. *If using a 3M™ Shearbolt Connector QCI Series for 500 kcmil to 500 kcmil splices, use the QS4-15SP-QCI-500-750-BCA kit or the QS4-15SP-500-1000-BCA kit with the QCI 350-750 connector purchased separately.
Typical properties
| Application | Cable Connection |
| Cable Shielding | Jacketed Concentric Neutral (JCN), Longitudinally Corrugated (LC), Tape Shield, Flat Strap Neutral |
| Case Quantity | 1 |
| Conductor Material | Aluminum, Copper |
| Conductor Sizes (Imperial) | 1 AWG, 2 AWG, 1/0 AWG, 2/0 AWG, 3/0 AWG, 4/0 AWG, 250 kcmil, 300 kcmil, 350 kcmil, 400 kcmil, 500 kcmil, 600 kcmil, 650 kcmil, 700 kcmil, 750 kcmil, 800 kcmil, 900 kcmil, 1000 kcmil |
| Conductor Sizes (Metric) | 95 mm² |
| Conductor Type | Aluminum or Copper |
| Connector Included | Yes, No |
| Dielectric Strength (V/mil) | 370 v/Mil |
| For Use With | Aluminum and/or Copper Conductors |
| For connection of paper - with plasticinsulated cables | No |
| Indoor/Outdoor | Both |
| Insulation Level | 1.33, 100%, 133% |
| Insulation Outer Diameter (Imperial) | 0.64 in, 0.65 in, 0.66 in, 0.67 in, 0.68 in, 0.69 in, 0.7 in, 0.71 in, 0.72 in, 0.73 in, 0.74 in, 0.75 in, 0.76 in, 0.77 in, 0.78 in, 0.79 in, 0.8 in, 0.81 in, 0.82 in, 0.83 in, 0.84 in, 0.85 in, 0.86 in, 0.87 in, 0.88 in, 0.89 in, 0.9 in, 0.91 in, 0.92 in, 0.93 in, 0.94 in, 0.95 in, 0.96 in, 0.97 in, 0.98 in, 0.99 in, 1 in, 1.01 in, 1.02 in, 1.03 in, 1.04 in, 1.05 in, 1.06 in, 1.07 in, 1.08 in, 1.09 in, 1.1 in, 1.11 in, 1.12 in, 1.13 in, 1.14 in, 1.15 in, 1.16 in, 1.17 in, 1.18 in, 1.19 in, 1.2 in, 1.21 in, 1.22 in, 1.23 in, 1.24 in, 1.25 in, 1.26 in, 1.27 in, 1.28 in, 1.29 in, 1.3 in, 1.31 in, 1.32 in, 1.33 in, 1.34 in, 1.35 in, 1.36 in, 1.37 in, 1.38 in, 1.39 in, 1.4 in, 1.41 in, 1.42 in, 1.43 in, 1.44 in, 1.45 in, 1.46 in, 1.47 in, 1.48 in, 1.49 in, 1.5 in, 1.51 in, 1.52 in, 1.53 in, 1.54 in, 1.55 in, 1.56 in, 1.57 in, 1.58 in, 1.59 in, 1.6 in, 1.61 in, 1.62 in, 1.63 in, 1.64 in, 1.65 in, 1.66 in, 1.67 in, 1.68 in, 1.69 in, 1.7 in |
| Insulation Outer Diameter (Metric) | 16.3 mm, 21.3 mm, 25.7 mm, 26.4 mm, 27.4 mm, 35.1 mm, 43.2 mm |
| Material | Silicone Rubber |
| Maximum Conductor Size (Imperial) | 4/0 AWG, 500 kcmil, 600 kcmil, 750 kcmil, 1000 kcmil |
| Maximum Conductor Size (Metric) | 95 mm², 240 mm², 300 mm², 325 mm², 500 mm² |
| Minimum Conductor Size (Imperial) | 2 AWG, 4/0 AWG, 350 kcmil, 500 kcmil |
| Minimum Conductor Size (Metric) | 35 mm², 95 mm², 185 mm², 240 mm² |
| Number of Conductors | 1 |
| Product Color | Black |
| Product Series | 15-SP |
| Product Type | Splice |
| Splice Type | Cold Shrink |
| Units per Case | 1.0 |
| Voltage | 15 kV |
| With Screw Connectors | No |
