3M™ Double Coated Tape 9741

  • Options available
  • | Select product options for IDs.

Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications

High tack for flying splices

Bonds well to most substrates, including low surface energy films

View more details
icn_down_arrow
icn_down_arrow
icn_down_arrow

Select product options

Details

Highlights
  • Ultra-high peel strength and excellent shear strength to withstand rigorous splicing applications
  • High tack for flying splices
  • Bonds well to most substrates, including low surface energy films
  • Excellent UV and heat resistance withstands a variety of conditions
  • Conformable to bond to irregular surfaces
  • Double sided adhesion increases dimensional stability for easy handling
  • Red option available for visible splicing applications

3M™ Double Coated Tape 9741 is a clear polyester film tape with a super aggressive, pressure sensitive acrylic adhesive and a glassine release liner. This tape uses a hand-tearable polyester film that is coated on both sides with a heavy layer of adhesive to allow for superior bonding and conformability to irregular as well as flat surfaces.

Clear double coated tape 9741
Bonds and conforms to both irregular and flat surfaces
Thick and Versatile
3M™ Double Coated Tape 9741 is a 6.5 mil double-sided tape utilizing a 0.5 mil hand-tearable polyester film carrier lined on both sides with acrylic adhesive. It has a high coat weight and adheres well to low surface energy substrates. This product provides excellent UV and heat resistance, and can perform under a wide temperature range (-40°F/-40°C to 200°F/93°C). Once bonded, this tape provides excellent peel and shear strength - making it ideal for rigorous splicing applications and bonding plastics to metals. 3M™ Double Coated Tape 9741 is mounted on a 55# glassine backing to enable ease of deployment. Notably, this product is offered in two colors — clear and red. The red version can be used for visible splicing applications.

Recommended Applications
  • High speed splicing applications
  • Applications where adhesion to low surface energy substrates is needed
  • Bonding decorative trim, plastics and metal profile extrusions
  • Attachment to irregular surfaces
  • Seaming of vinyl banners
  • Universal all-purpose bonding applications common to double coated tapes
Aggressive Adhesion
3M™ Double Coated Tape 9741 is coated on both sides with an aggressive, pressure sensitive acrylic adhesive. This bonding agent provides an ultra-high peel acrylic adhesive system that bonds well to most substrates, including low surface energy plastics. It provides superior bonding and conformability to irregular as well as flat surfaces. It will withstand a wide range of temperatures and applications.

Red double coated tape 9741
Red option allows better splicing visibility
What is Double Coated Tape?
In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in web processing, construction, fabrication, arts and hobby industries, among others.

Learn more about 3M™ Splicing Tapes (PDF, 747.28 Kb)

Typical properties

Adhesive Type

Acrylic

Application

Zero-Speed and General Splicing

Backing (Carrier) Material

Polyester, Polyester Film

Backing (Carrier) Thickness (Imperial)

0.5 mil

Backing (Carrier) Thickness (Metric)

0.013 mm

Brands

3M™

Carrier Material

Polyester Film

Carrier Thickness

0.5 mil

Carrier Thickness (Metric)

0.013 mm

Face Side Adhesive Type

Acrylic

Industries

Medical, Automotive, General Industrial, Specialty Vehicle, Transportation, Appliance, Electronics

Maximum Operating Temperature (Fahrenheit)

200 ℉

Number of Adhesive Sides

Double-sided

Primary Liner

55# Glassine

Primary Liner Color

White

Product Color

Transparent

Product Form

Roll

Tape Type

Double Coated

Total Tape Thickness without Liner (Imperial)

6.5 mil

Total Tape Thickness without Liner (Metric)

0.165 mm

Units per Case

16.0, 32.0, 48.0

Overall Length (Imperial)

60.15 yd

Overall Length (Metric)

55 m

Overall Width (Imperial)

0.95 in, 1.42 in, 1.9 in, 2.83 in

Overall Width (Metric)

24 mm, 36 mm, 48 mm, 72 mm

Resources

Regulatory Data Sheet

Document Number: MSDS_4381661_US_EN_RDS

(PDF)
