3M™ Double Coated Tape 9443NP features 3M™ Adhesive 760, a high-tack synthetic rubber adhesive that bonds a wide variety of substrates including metals, papers, paints and most plastics. This tape provides excellent initial adhesion and is somewhat repositionable.
Long Lasting Performance
3M™ Double Coated Tape 9443NP is a 6 mil tape built on a high density polyethylene (HDPE) carrier. This strong, lightweight film carrier provides dimensional stability for aid in removal and also provides easier handling during slitting and die-cutting. A 62# densified kraft paper liner improves handling, protects against humidity and is ideal for die-cutting and laminating.
The aggressive synthetic rubber adhesive, 3M Adhesive 760, provides high initial adhesion and is somewhat repositionable for proper placement of bonded materials. It features excellent adhesion to both high surface energy and low surface energy plastics and is an excellent choice for many interior applications such as for bonding polyethylene.
Double Coated Tapes Provide Solutions for Many Bonding Applications
In general, double coated tape is composed of a paper, film, or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts, and hobby.
Recommended Applications
Bringing Better Ideas to the Surface through Science and Innovation
In our 3M Industrial Adhesives and Tapes Division, we apply the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, our technologies help customers like you deliver competitive products to the market faster and more efficiently.
| Adhesive Type | Synthetic Rubber |
| Back Side Adhesive Thickness (Imperial) | 2 mil |
| Back Side Adhesive Thickness (Metric) | 0.051 mm |
| Back Side Adhesive Type | Synthetic Rubber Adhesive 760 |
| Backing (Carrier) Material | HDPE |
| Backing (Carrier) Thickness (Imperial) | 2 mil |
| Backing (Carrier) Thickness (Metric) | 0.051 mm |
| Brands | 3M™ |
| Carrier Material | High Density Polyethylene HDPE |
| Carrier Thickness | 0.13681 mil |
| Carrier Thickness (Metric) | 0.05 mm |
| Core Size (Imperial) | 3 in |
| Core Size (Metric) | 76.2 mm |
| Face Side Adhesive Thickness (Imperial) | 2 mil |
| Face Side Adhesive Thickness (Metric) | 0.051 mm |
| Face Side Adhesive Type | Synthetic Rubber Adhesive 760 |
| Indoor/Outdoor | Both |
| Industries | Packaging, Craft, Point of Purchase, Construction, Metalworking, Food and Beverage, General Industrial, Print, Signage, Converter Solutions |
| Master Size Length (Imperial) | 120 Linear Yard |
| Master Size Length (Metric) | 109.7 m |
| Master Size Width (Imperial) | 27 in |
| Master Size Width (Metric) | 69 cm |
| Maximum Operating Temperature (Celsius) | 49 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 120 ℉ |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Primary Liner | 62# Densified Kraft Paper (DK) |
| Primary Liner Color | White |
| Primary Liner Thickness (Imperial) | 3.7 mil |
| Primary Liner Thickness (Metric) | 0.09 mm |
| Product Color | Transparent |
| Product Form | Roll |
| Smallest Saleable Unit | Roll |
| Total Tape Thickness without Liner (Imperial) | 6 mil |
| Total Tape Thickness without Liner (Metric) | 0.152 mm |
| Units per Case | 36.0 |
| Overall Length (Imperial) | 60 yd |
| Overall Length (Metric) | 54.86 m |
| Overall Thickness (Imperial) | 6 mil |
| Overall Width (Imperial) | 1 in, 27 in |
| Overall Width (Metric) | 25.4 mm, 685.8 mm |
