3M™ Four-Wall Header Straight Compliant Pin 3000 Series
- 3M Product Number 3000 Series
- 3M ID B00046666
- UPC 08887862422612
Details
Highlights
- Military and centerbump polarization helps minimize inaccurate connections
- Eye-of-the needle pin design allows precise contact
- Mounting holes help simplify board attachment
- Polarizing posts are optional for accurate alignment
- Optional ejector latches help make connections secure even in demanding environments
The 3M™ Four-Wall Header Straight Compliant Pin 3000 Series is excellent for electronics applications where accurate connections are critical. The header features military and centerbump polarization, and an eye-of-the needle pin design makes for precise connections with minimal rework. Mounting holes make it simpler to secure the header to the PCB.
With optional polarizing posts and optional ejector latches, 3M™ Four-Wall Header Straight Compliant Pin 3000 Series makes for fast and secure wire-to-board connections.
Typical properties
| Application | Wire-to-board Connecting |
| Connector Shape | Rectangular |
| Connector Style | Plug, Header |
| Contact Base Material | Copper Alloy |
| Current Rating | 1.0 A |
| Factory ISO Certification | No ISO Certification information available |
| Features | Mounting Flange |
| Insulation Color | Black |
| Insulation Height (Imperial) | 0.68 in |
| Insulation Height (Metric) | 17.27 mm |
| Insulation Material | Glass Filled Polyester (PBT) or High Temperature (PCT) |
| Latch/Ejector Type | Latch Lock/Eject Hooks (Long), Latch Lock/Eject Hooks (Short), Push-in/Pull-out |
| Mating Contact Finish Material | Gold |
| Mating Option | Board to Cable, Board to Wire |
| Maximum Operating Temperature (Celsius) | 105 ℃ |
| Maximum Operating Temperature (Fahrenheit) | 221 ℉ |
| Minimum Operating Temperature (Celsius) | -55 ℃ |
| Minimum Operating Temperature (Fahrenheit) | -67 ℉ |
| Number of Contact Rows | 2 |
| Number of Contacts | 10 , 14 , 16 , 20 , 24 , 30 , 34 , 40 , 50 , 60 , 64 |
| PCB Mounting Angle | Straight |
| PCB Mounting Style | Through Hole |
| Pitch (Imperial) | 0.079 in |
| Pitch (Metric) | 0.1 mm |
| Post Contact Finish Material | Matte Tin |
| Product Series | 3000 |
| Shroud Style | 4 Wall |
| Specifications Met | UL 94V-0 |
| Tech Sheet Number | TS-0478 |
| Voltage Rating | 1000 Vrms at Sea Level |
